Inconel 718 does not cut like aluminium: low thermal conductivity means heat stays at the tool tip rather than carrying away in the chip, so speeds and feeds are set for tool life first and cycle time second. We rough this segment soft, before the age-hardening heat treat the drawing calls for, then finish-grind the sealing faces afterward — cutting it hard from bar stock would burn through carbide inserts in minutes.
Part
Turbine Shroud Segment
A nickel superalloy segment machined for a hot-section application — roughed soft, heat treated, then finished to a ground tolerance the as-cast blank could never hold.
Part
Turbine Shroud Segment
Rev
Rev D
Year
2026
Material
Inconel 718
Tightest tolerance
±0.013mm (13 µm), position to datums A|B|C
Lot
18-off, running lot
Lead time
34 days
Route sheet
How this part actually got made.
| Op | Stage | Machine | Tool | Result |
|---|---|---|---|---|
| 01 | Stock | Material stores | — | Saw-cut billet, certificate matched to the traveler. |
| 02 | Face | Haas VF-2, 3-axis vertical mill | Ø12mm ball-nose, 2-flute carbide | Rz ≈ 190.52 µm |
| 03 | Haas VF-2, 3-axis vertical mill | Ø8mm ball-nose, 2-flute carbide | Rz ≈ 127.02 µm | |
| 04 | Drill | Haas VF-2, 3-axis vertical mill | Ø6mm jobber drill, HSCO | — |
| 05 | Heat treat | Outside process — subcontracted | — | Certificate returned with the lot; hardness re-verified on receipt. |
| 06 | Grind | Studer S31, cylindrical grinder | Ø8mm ball-form CBN wheel | Rz ≈ 2.81 µm |
| 07 | Inspect | Zeiss Contura CMM | — | First-article report against the drawing's GD&T callouts. |
Finish
Specified surface finish.
What the drawing calls out — verified on receipt with a profilometer, not assumed from the tool that made it.
Ra0.80 µm
